Danfoss MBS 3000-2631-A1AB04-0
Danfoss MBS 3000 0–40 bar gauge, G 1/4 male, 4–20 mA 2-wire, 316L, DIN connector
Danfoss MBS 3000 pressure transmitter for general industrial purposes, 0-40 bar (0-580 psi), 4-20 mA two-wire output, 9-32 V DC supply, AISI 316L wetted parts and 316L enclosure, G 1/4 male process connection, Pg 9 angular connector to EN 175301-803-A, IP65 with the connector fitted and tightened, non-linearity ±0.5% FS (BFSL) with typical accuracy ±0.5% FS and maximum ±1% FS, compensated 0 to 80 C, medium temperature -40 to 85 C, overload 240 bar, response time 4 ms, cULus and CE. Widely used in hydraulics, refrigeration and general industrial control loops. Wiring matches the WIKA A-10 that this entry cross-references: supply positive on pin 1, common on pin 2, so the existing plug can be reused as terminated. Differences the buyer should note: this build is a sealed-gauge instrument referenced to 1 bar absolute where the WIKA A-10 is a vented gauge instrument, and Danfoss catalogues a vented relative-gauge MBS 3000 on this connector and connection only up to 0-16 bar; the process connection is G 1/4 A to EN 837, which seals on a flat gasket face, where the WIKA is G 1/4 A to DIN EN ISO 1179-2, which seals on an elastomer ring at the shoulder, and this build is supplied with no gasket, so the correct seal must be ordered separately; the supply range is 9-32 V DC against 8-30 V DC on the WIKA, so the two overlap at 24 V but the Danfoss will not run as low; and the pressure-cycle rating is above 10 million against 100 million for the WIKA.
Specifications of the Danfoss part
- Measuring Range
- 0–40 bar gauge
- Output
- 4–20 mA, 2-wire
- Process Connection
- G 1/4 male
- Wetted Material
- 316L stainless steel
- Supply Voltage
- 7–32 V DC
- IP Rating
- IP67
- Non-Linearity
- ≤ ±0.5% FS
- Connector
- DIN 43650 valve connector
