WIKA Pressure Gauge 111.10.100, 0...1500 psi, Dry Black Plastic Case, Dual Scale, 4" Dial, 1/2" Male NPT Lower Mount, 13380010
Part no. 13380010
In stock, 18 available
Bourdon Tube Pressure Gauges
WIKA
WIKA Pressure Gauge 213.53.100, 0...15000 psi, Dual Scale, 4" Dial, 1/2" Male NPT Lower Back Mount, 84254745
- Mfr. part no.
- 84254745
- SKU
- PW40-BC-15000
Specifications
| Model | 213.53.100 |
|---|---|
| Measuring System | Bourdon Tube |
| Dial Size | 100 mm / 4" |
| Measuring Range | 0...15000 psi |
| Secondary Scale | 2nd scale bar |
| Process Connection | 1/2" Male NPT |
| Mounting Position | Lower back mount |
| Mounting Flange | Polished SS front flange |
| Case Filling | Dry Case, Prepared for filling |
| Wetted Parts | Copper alloy |
| Case Material | Stainless steel 1.4301 |
| Case Design | Crimp ring case (version 53) |
| Accuracy Class | Class 1.0 |
| Window | Plastic, clear |
Key Features
- Lower back mount 1/2" Male NPT connection with polished stainless steel front flange supports panel mounting.
- Stainless steel case provides strong protection for industrial pressure monitoring.
- Dual scale dial shows psi as the primary scale with a red bar secondary scale.
- Prepared for liquid filling to support service with vibration or dynamic pressure loads.
- 100 mm dial and class 1.0 accuracy support clear everyday reading.
- Made in Poland
Description
This WIKA 213.53.100 bourdon tube pressure gauge is designed for accurate pressure monitoring in hydraulic equipment, compressors, pumps and general industrial systems. It has a 4" dial with a 1/2" Male NPT lower back mount connection and a stainless steel case with polished SS front flange for dependable panel installation. The gauge is prepared for liquid filling, which makes it suitable for installations where vibration resistance may be required. It features a 0...15000 psi range with class 1.0 accuracy and a clear dial that is easy to read. The dial shows a black primary psi scale with a red secondary bar scale for quick cross reference. This model is a practical choice for reliable pressure indication across a wide range of industrial duties.
Applications
- Hydraulic systems
- Air compressors
- Pump skids
- Industrial utilities
- Vibration service
