WIKA Pressure Gauge 213.53.100, 0...1000 psi, Dual Scale, 4" Dial, 1/2" Male NPT Lower Back Mount, 39001831
Technical overview
This WIKA 213.53.100 bourdon tube pressure gauge is designed for accurate pressure monitoring in hydraulic equipment, compressors, pumps and general industrial systems. It has a 4" dial with a 1/2" Male NPT lower back mount connection and a stainless steel case with polished SS front flange for dependable panel installation. The gauge is prepared for liquid filling, which makes it suitable for installations where vibration resistance may be required. It features a 0...1000 psi range with class 1.0 accuracy and a clear dial that is easy to read. The dial shows a black primary psi scale with a red secondary bar scale for quick cross reference. This model is a practical choice for reliable pressure indication across a wide range of industrial duties.
Key Features
- Lower back mount 1/2" Male NPT connection with polished stainless steel front flange supports panel mounting.
- Stainless steel case provides strong protection for industrial pressure monitoring.
- Dual scale dial shows psi as the primary scale with a red bar secondary scale.
- Prepared for liquid filling to support service with vibration or dynamic pressure loads.
- 100 mm dial and class 1.0 accuracy support clear everyday reading.
- Made in Poland
Applications
- Hydraulic systems
- Air compressors
- Pump skids
- Industrial utilities
- Vibration service
Specifications
Model213.53.100
Measuring SystemBourdon Tube
Dial Size100 mm / 4"
Measuring Range0...1000 psi
Secondary Scale2nd scale bar
Process Connection1/2" Male NPT
Mounting PositionLower back mount
Mounting FlangePolished SS front flange
Case FillingDry Case, Prepared for filling
Wetted PartsCopper alloy
Case MaterialStainless steel 1.4301
Case DesignCrimp ring case (version 53)
Accuracy ClassClass 1.0
WindowPlastic, clear
