Mitutoyo Series 186 Radius Gage Set, 0.4 to 6.0 mm Range, 18 Leaves, 90 Degree Arc, 186-110
All Mitutoyo products
Mitutoyo Dimensional Measuring Tools
All Dimensional Measuring Tools (every brand)
Technical overview
Mitutoyo 186-110 / RG-D4 is a Series 186 metric radius gauge set for checking small concave and convex radii from 0.4 to 6 mm. The set includes 18 stamped leaves covering 0.4, 0.8, 1, 1.2, 1.5, 1.6 mm, 1.75 to 3 mm by 0.25 mm and 3.5 to 6 mm by 0.5 mm, with each leaf combining internal and external radius gauges of the same size. The 90 degree arc design and locking clamp make it useful for tool rooms, machining inspection, die work, fabrication and maintenance checks where quick radius verification is required.
Key Features
- Each leaf combines internal and external radius checking.
- Radius size is stamped on each gage leaf for easy selection.
- 90 degree arc profile suits small radius inspection.
- 18-leaf metric set covers 0.4 to 6.0 mm radius sizes.
- Includes: Operating Instructions paperwork inside the box.
- Made in Japan.
Applications
- Checking edge radii, fillets and machined profiles.
- Tool room, die work and fabrication inspection.
- Matching internal and external radii on replacement parts.
Specifications
Series186 Series
Product TypeRadius Gauge Set
Measuring Range0.4 to 6.0 mm
Number of Leaves/Anvils18
ModelRG-D4
