Mitutoyo TI-123AX, Series 513 Dial Test Indicator, 1 mm Range, 0.01 mm Graduation, Plus Set, 513-415-10A
Part no. 513-415-10A
In stock, ships in 2 to 3 days
Specifications
| Product Type | Standard Dial Indicator |
|---|---|
| Measuring Range | 5 mm |
| Graduation | 0.01 mm |
| Accuracy | 12 µm |
| Body Material | Metal Indicator Body |
| Measuring Face | Carbide Tipped |
| Stem Diameter | 8 mm |
Key Features
- Standard lug-back dial indicator for general mechanical measurement.
- Metal indicator body with hardened stainless stem supports routine shop use.
- Carbide-tipped contact point improves wear resistance at the measuring tip.
- Bezel clamp and lifting lever can be fitted on either side.
- O-ring and sealed bezel assembly help reduce oil and water penetration.
- Made in Japan.
Description
Mitutoyo 2044A is a standard analog dial indicator for checking runout, flatness, alignment and small displacement in fixtures and machine setups. It provides 5 mm range with 0.01 mm graduation in a metal indicator body with hardened stainless stem and carbide-tipped contact point for regular industrial inspection use. The sealed bezel assembly, O-ring construction and optional bezel clamp or lifting lever support practical use on shop-floor measuring stands and gauges.
Applications
- Runout, alignment and comparative measurement checks.
- Surface plate, fixture and machine setup inspection.
- Use with magnetic stands, holders and height gauges.
- Quality control and maintenance measurement of mechanical parts.
