Mitutoyo Series 187 Universal Bevel Protractor, Mechanical Vernier Angle Gauge, 5 Minute Graduation, 187-901-10
Mitutoyo

Mitutoyo Series 187 Universal Bevel Protractor, Mechanical Vernier Angle Gauge, 5 Minute Graduation, 187-901-10

Mfr. part no.
187-901-10
SKU
MT-187-901-10

Specifications

Product Type Universal Bevel Protractor
Model 187-901-10
Measurement Type Mechanical Vernier Angular Measurement
Measuring Range 0 to 360°
Display Resolution 5′ (5 Arc Minutes)
Measuring Face Stainless Steel Measuring Blade
Output Signal None, Mechanical Measurement
Series Series 187

Key Features

  • Mechanical vernier scale for fine angle measurements.
  • 5 minute vernier graduation typical of the Series 187 design.
  • Adjustable stainless steel measuring blade.
  • Blade locking mechanism maintains the selected setting.
  • Fine adjustment control for careful angle positioning.
  • Integrated magnifier assists scale readability.
  • Made in Japan.

Description

The Mitutoyo Series 187 universal bevel protractor is used to measure and transfer workpiece angles in machine shops, toolrooms and quality-control departments. It features a circular main scale, mechanical vernier reading, adjustable blade with a locking mechanism, fine adjustment and a built-in magnifier for easier angle reading. The instrument is suitable for inspection of bevels, machine setups, moulds and jigs.

Applications

  • Inspection of angled and bevelled machined surfaces.
  • Tool and die manufacturing and inspection.
  • Machine setup and angular alignment.
  • Checking angles on moulds, jigs and fixtures.
  • Transferring and setting workpiece angles.

Documents

  • Mitutoyo-187-901-10 — Datasheet

    PDF, 494 KB
