WIKA Pressure Gauge 212.53.100, 0...60 bar, Dual Scale, 4" Dial, 1/2" Male NPT Lower Mount, 39902204
Technical overview
This WIKA 212.53 bourdon tube pressure gauge is designed for accurate pressure monitoring in hydraulic equipment, compressors, pumps and general industrial systems. It has a 4" dial with a 1/2" Male NPT brass lower connection and a stainless steel case for dependable everyday service. The gauge is prepared for liquid filling, which makes it suitable for installations where vibration resistance may be required. It features a 0...60 bar range with class 1.0 accuracy and a clear dial that is easy to read. The dial shows a black primary bar scale with a red secondary psi scale for quick cross reference. This model is a practical choice for reliable pressure indication across a wide range of industrial duties. This gauge can also marked as WIKA’s current part number 84293538, which corresponds to the exact matching configuration of this product.
Key Features
- Stainless steel case provides strong protection for industrial pressure monitoring.
- 1/2" Male NPT brass lower connection supports common installation points.
- Dual scale dial shows bar as the primary scale with a red psi secondary scale.
- Prepared for liquid filling to support service with vibration or dynamic pressure loads.
- 100 mm dial and class 1.0 accuracy support clear everyday reading.
- Made in Poland
Applications
- Hydraulic systems
- Air compressors
- Pump skids
- Industrial utilities
- Vibration service
Specifications
Model212.53.100
Measuring SystemBourdon Tube
Dial Size100 mm / 4"
Measuring Range0...60 bar
Secondary Scale2nd scale psi
Process Connection1/2" Male NPT
Mounting PositionLower mount
Case FillingDry case, prepare for filling
Wetted PartsCopper alloy
Case MaterialStainless steel 1.4301
Case DesignCrimp ring case (version 53)
Accuracy ClassClass 1.0
WindowPlastic, clear
