Bourdon Tube Pressure Gauges
General Instruments Pressure Gauge SPGS-V, 0...60 psi, 2nd Scale bar, 2.5" Dial, 1/4" Male NPT Lower Mount, SS Body & Parts, SPGS-V-063-S4S-S6S-S6S-S4S-T06NTM-(0-60)-PSI/BAR-A16-DUS
General Instruments

General Instruments Pressure Gauge SPGS-V, 0...60 psi, 2nd Scale bar, 2.5" Dial, 1/4" Male NPT Lower Mount, SS Body & Parts, SPGS-V-063-S4S-S6S-S6S-S4S-T06NTM-(0-60)-PSI/BAR-A16-DUS

Mfr. part no.
SPGS-V-063-S4S-S6S-S6S-S4S-T06NTM-(0-60)-PSI/BAR-A16-DUS
SKU
PS250-00060-GG

Specifications

Model SPGS-V
Measuring System Bourdon Tube
Dial Size 63 mm / 2.5"
Measuring Range 0...60 psi
Secondary Scale 2nd scale bar
Process Connection 1/4" Male NPT
Mounting Position Lower mount
Case Filling Dry case, prepared for filling
Wetted Parts SS316
Case Material SS304
Accuracy Class Class 1.6
Window Glass, clear
Over Range 125% FSD
Pressure Gauge Standard EN 837-1
Ambient Temperature Range -20...+60°C
Blow Out Disc Provided on top of case (Neoprene)

Key Features

  • 2.5" / 63 mm dial for clear compact pressure indication.
  • Primary psi scale with 2nd scale bar for quick reference.
  • 1/4" Male NPT process connection for industrial installation.
  • Stainless steel made body with SS316 wetted parts.
  • Dry case, prepared for filling for service with vibration or dynamic pressure loads.
  • Glass window and Class 1.6 accuracy for dependable local reading.
  • Lower mount for direct process installation.
  • Made in India.

Description

General Instruments pressure gauge Model SPGS-V is designed for reliable local pressure indication in demanding industrial service. The gauge uses a 2.5" / 63 mm dial with a 1/4" Male NPT lower connection for direct process installation. Stainless Steel Made, with glass window, SS316 wetted parts and a dry case prepared for filling where vibration or dynamic pressure conditions require liquid filling. Measuring range is 0...60 psi with 2nd scale bar, accuracy class is Class 1.6, and the compact design is suitable for hydraulic lines, pneumatic systems, pump skids, compressor systems and general process duties.

Applications

  • Hydraulic and pneumatic pressure monitoring.
  • Pump, compressor and utility line pressure indication.
  • Industrial machinery, skids and process panels.
  • General process service requiring compact local indication.

Documents

  • General Pressure Gauges SPGS-63 mm Dial — Datasheet

    PDF, 124 KB

Cross-reference

The closest equivalents from other brands, with the differences stated so you can check before you order.

Ashcroft 25-1009-SW-02L-60#

2.5" SS316 dry pressure gauge, 0-60 psi/bar, 1/4" NPT LM, Class 1.6

Ashcroft Type 1009 Duralife is a 2½” (63 mm) all-stainless Bourdon tube pressure gauge. In the build 25-1009-SW-02L-60# it carries a 316 stainless steel Bourdon tube with a 316L stainless steel process connection, a 304 stainless steel case and bayonet ring, a 1/4" NPT male lower-mount connection and a 0-60 psi range, supplied dry and field fillable. Accuracy is ±1% of span, ASME B40.100 Grade 1A. Two differences a buyer should note before cross-ordering. First, the Ashcroft 1009 dial is single-unit: 0-60 psi is the 60# dial and bar is ordered as a separate 4BR dial, so the Ashcroft has no psi/bar dual scale, whereas the gauge listed here carries a bar second scale in addition to the psi scale. Second, the standard 1009 lens is polycarbonate, with safety glass available only as an option, whereas the gauge listed here has a clear glass window as standard.

Specifications of the Ashcroft part

Dial Size
2.5" / 63 mm
Range
0-60 psi / bar
Connection
1/4" NPT male, lower mount
Wetted Material
SS316
Case Material
Stainless Steel
Accuracy Class
ASME Grade 1A (~Class 1.6)
Window
Glass
Fill
Dry / fillable

Swagelok PGI-63B-PG60-LAOX

2.5" SS316 pressure gauge, 0-60 psi, 1/4" NPT LM, liquid-fillable

Swagelok PGI series 63 mm stainless steel pressure gauge with 1/4" NPT lower mount, SS316 wetted parts, and 0-60 psi range. The LAOX suffix denotes dual PSI/bar scale and fillable dry case construction. Designed for demanding process and instrumentation service with high vibration resistance when filled.

Specifications of the Swagelok part

Dial Size
63 mm / 2.5"
Range
0-60 psi
Connection
1/4" NPT male, lower mount
Wetted Material
SS316
Case Material
Stainless Steel
Accuracy Class
±1.5% ASME Grade 1A
Fill
Dry / fillable

We carry SPGS-V-063-S4S-S6S-S6S-S4S-T06NTM-(0-60)-PSI/BAR-A16-DUS as the indSpare-stocked equivalent. Looking for a different brand? Request a quote →
