Suco 0166 Series Diaphragm Pressure Switch, G 1/4" Connection, 1-10 bar, Normally Closed, 0166-40603-1-023
Suco

Suco 0166 Series Diaphragm Pressure Switch, G 1/4" Connection, 1-10 bar, Normally Closed, 0166-40603-1-023

Mfr. part no.
0166-40603-1-023
SKU
SUCO-0180-45703-1-106

Specifications

Working Pressure Range 1-10 bar
Switching Function Normally Closed (NC)
Process Connection G 1/4" Male
Rated Voltage 10-42 V AC/DC
Overpressure Safety Up to 300 bar, static
Seal Material NBR
Rated Current 10 mA-4 A

Key Features

  • Adjustable pressure range from 1 to 10 bar
  • Normally closed switching function
  • G 1/4 male process connection
  • M3 screw terminals
  • 10 to 42 V AC/DC rated working voltage
  • NBR diaphragm seal for hydraulic oil, machine oil, air and nitrogen applications
  • Static overpressure safety up to 300 bar
  • Made in Germany.

Description

The SUCO 0166-40603-1-023 is a compact mechanical diaphragm pressure switch for monitoring liquid and gaseous pressure in hydraulic, pneumatic and general industrial systems. It has a 1 to 10 bar adjustment range with a normally closed contact, G 1/4" male process connection and M3 screw terminals. This unit is not factory-adjusted, allowing the switching point to be set within the specified range when installed. It is rated for 10 to 42 V AC/DC, 10 mA to 4 A and 100 W / 100 VA switching power, and uses an NBR seal. The diaphragm design provides static overpressure safety up to 300 bar, while IP65 protection is achieved with a suitable socket device.

Applications

  • Hydraulic pressure monitoring
  • Pneumatic systems and compressed air equipment
  • Pumps and compressor control
  • Industrial machinery and machine tools
  • Lubrication and oil pressure monitoring
  • Air and nitrogen pressure switching

Documents

  • Suco Pressure Switches hex-24 — Datasheet

    PDF, 603 KB
