PCH 1106 Compact Vibration Sensor, 0-50 mm/s, M12 8-Pin, PCH1106 / CHF8170/X1
.webp)
KWD 400.000
Lead time: 9 weeks
All PCH Engineering products
PCH Engineering Vibration Measurement
All Vibration Measurement (every brand)
Technical overview
PCH Engineering PCH1106/CHF8170/X1 is a compact vibration velocity sensor designed for continuous condition monitoring of rotating machinery. It measures vibration velocity from 0 to 50 mm/s using True RMS detection over a 10 to 1000 Hz frequency range and provides a 4-20 mA analog signal for connection to PLC and machine-monitoring systems. The sensor uses a capacitive accelerometer housed in stainless steel 1.4305, an M12 8-pin top connector and an integrated M8 mounting stud. It is suitable for monitoring vibration caused by machine conditions such as unbalance and misalignment on pumps, fans, ventilators, separators and similar rotating equipment.
Key Features
- 0-50 mm/s vibration velocity measuring range
- True RMS vibration measurement over 10-1000 Hz
- 4-20 mA analog output for PLC and monitoring systems
- Special M12 8-pin electrical connection
- Capacitive accelerometer with ±5% measuring accuracy
- Stainless steel 1.4305 housing with integrated M8 mounting stud
- Designed for continuous monitoring of rotating machinery
Applications
- Pumps and pump bearing housings
- Industrial fans and ventilators
- Separators and decanters
- Mills and other rotating production equipment
- Monitoring machine unbalance and misalignment
- PLC-based vibration and condition monitoring systems
Specifications
Measuring SystemCapacitive Accelerometer
Measuring Range0-50 mm/s
Frequency10-1000 Hz
Measurement MethodTrue RMS
Output Signal4-20 mA
Power Supply18-30 V DC
Electrical ConnectionM12, 8-Pin
