RIV 250 Opale Series Pressure Relief Valve with Hose-Connection, 1-1/2" BSPP Inlet, 0.5-1.5 bar, 050250000009

Part Number : 050250000009

Brand :
RIV

The RIV 250 Opale is a spring-operated, adjustable low-pressure relief valve with a hose outlet that lets you route any vented leakage into a safe tank, ideal for protecting low-pressure vessels/systems while keeping discharge controlled.

Serving Kuwait, Saudi Arabia and entire GCC with express delivery.

View all

KWD 19.000

Quantity

Shipping will be calculated at checkout after you enter delivery address.

In stock (15 available).

Available Qty: 15

Description
Specifications
Downloads
Related products

Description

RIV 250 Opale is a spring operated pressure relief valve designed for low-pressure protection with an environmentally safer discharge method. The inlet is a 1-1/2" ISO 228/1 BSPP Thread, while the outlet is a hose connection with 45 mm hose diameter, allowing you to connect a hose/pipe and direct any vented leakages into a proper tank. The relief setting is adjustable from 0.5 to 1.5 bar (7–21 psi), and the valve is rated for 1.5 bar (21 psi) working pressure in this range. Construction includes a brass body with FKM sealing for durability in demanding service conditions.

Key Features

  • Spring operated relief design helps protect low-pressure systems from overpressure.
  • Adjustable set pressure range is 0.5–1.5 bar (7–21 psi) for on-site calibration.
  • Maximum working pressure rating is 1.5 bar (21 psi)
  • 1-1/2" ISO 228/1 (BSPP) thread inlet connection supports standard installation on compatible ports.
  • 45 mm hose outlet allows controlled discharge to a hose/pipe and safe routing into a collection tank.
  • Brass body with FKM sealing supports durability and reliable sealing in demanding service.
  • Tamper-proof sealing can be applied after adjustment using the drilled tongues method mentioned by suppliers.
  • Made in Italy.

Downloads

Datasheet Opale - RIV 250.pdf

pdf
Download

Riv_230_250_Setting_Instruction_UK.pdf

pdf
Download

Specifications

Series
RIV Opale 250
Valve Type
Spring operated relief, hose connection
Inlet port
1-1/2" ISO 228/1 (BSPP)
Outlet port
45 mm Hose Connection
Adjustable Pressure Range
0.5-1.5 bar (7-21 psi)
Max Working Pressure
1.5 bar (21 psi)
Temperature Range
0 to 180°C
Seal material
FKM
Compliance Standards
PED 2014/68/EU
Application
Slurry tanker overpressure protection
Body Material
Brass (CB754S)
