Mfg. Part No. : SPGS-P-063-S4S-S6S-S6S-S4S-T06NTM-(0-2000)-PSI/BAR-A16-DUS

SKU : PS250-BC-02000-GG

Brand :
General Instruments

General Instruments Model SPGS-P pressure gauge is a stainless steel made Bourdon tube gauge designed for reliable local pressure indication in demanding industrial service. It is suitable for pump lines, compressor systems, hydraulic and pneumatic equipment and general process duties, offering clear readability and a dry case prepared for filling where vibration or dynamic pressure loads are present.

General Instruments (General Gauges) India - KOC, KNPC, Saudi Aramco, QatarEnergy, SABIC approved pressure gauges, thermometers & process instruments since 1966.

Serving Kuwait, Saudi Arabia and entire GCC with express delivery.

View all
Quantity
In Stock  ·  10 available
Shipping calculated at checkout. Log in for an estimate.
Description
Specifications
Downloads
Related products

Description

General Instruments SPGS-P-063-S4S-S6S-S6S-S4S-T06NTM-(0-2000)-PSI/BAR-A16-DUS — General Instruments Pressure Gauge SPGS-P, 0...2000 psi, 2nd Scale bar, 2.5" Dial, 1/4" Male NPT Back Mount With Front Flange, SS Body & Parts, SPGS-P-063-S4S-S6S-S6S-S4S-T06NTM-(0-2000)-PSI/BAR-A16-DUS. Stocked by Indspare for Kuwait and GCC delivery.

General Instruments pressure gauge Model SPGS-P is designed for reliable panel-mounted pressure indication in demanding industrial service. The gauge uses a 2.5" / 63 mm dial with a 1/4" Male NPT back connection and a front flange for flush panel mounting. Stainless Steel Made, with glass window, SS316 wetted parts and a dry case prepared for filling where vibration or dynamic pressure conditions require liquid filling. Measuring range is 0...2000 psi with 2nd scale bar, accuracy class is Class 1.6, and the compact design is suitable for machinery panels, pump skids, compressor systems and general process duties.

Key Features

  • 2.5" / 63 mm dial for clear compact pressure indication.
  • Primary psi scale with 2nd scale bar for quick reference.
  • 1/4" Male NPT process connection for industrial installation.
  • Stainless steel made body with SS316 wetted parts.
  • Dry case, prepared for filling for service with vibration or dynamic pressure loads.
  • Glass window and Class 1.6 accuracy for dependable local reading.
  • Back mount with front flange for panel installation.
  • Made in India.

Applications

  • Hydraulic and pneumatic pressure monitoring.
  • Pump, compressor and utility line pressure indication.
  • Industrial machinery, skids and process panels.
  • General process service requiring compact local indication.

Downloads

General Pressure Gauges SPGS-63 mm Dial Datasheet.pdf

pdf
Download

Specifications

Model
SPGS-P
Measuring System
Bourdon Tube
Dial Size
63 mm / 2.5"
Measuring Range
0...2000 psi
Secondary Scale
2nd scale bar
Process Connection
1/4" Male NPT
Mounting Position
Back mount
Mounting Flange
SS front flange
Case Filling
Dry case, prepared for filling
Wetted Parts
SS316
Case Material
SS304
Accuracy Class
Class 1.6
Window
Glass, clear
Over Range
125% FSD
Pressure Gauge Standard
EN 837-1
Ambient Temperature Range
-20...+60°C
Blow Out Disc
Provided on top of case (Neoprene)
